OSPREYTalon Pro Streaming Encoder

Art.Nr. VS-OS-96-02022

Talon Pro Hardware Encoder

 https://www.riwit.de/web/image/product.template/6454/image_1920?unique=439729c

2,839.32 € 2,839.32 € 2839.32 EUR netto UVP

3,378.79 € 3,378.79 € 3378.7908 EUR brutto UVP

Option nicht verfügbar

Not Available For Sale

This combination does not exist.

Contact Us

Talon Pro features three simultaneous encoding channels up to 4K30.

 All channels are independent and can be mixed between HEVC and AVC encoding in different resolutions, frame rates and bit rates.

 With its built in Wifi Management capability the unit can be configured and controlled over Wifi or LAN HTTP Interface.

The fanless design combined with redundant power inputs make Talon Pro the perfect candidate for mission critical applications. Talon Pro supports two 3G-SDI plus one 4k30 HDMI Input.

  • H.265/H.264 Encoding

  • Three encoding channels

  • Redundant Power Inputs

  • Small Fanless Form Factor

  • 2x 3G-SDI, 1 x 4K30 HDMI 1.4

  • Unbalanced Stereo Audio Input

  • RTMP(S), RTP, RTPS, TSRTP and UDP

  • CEA608 and CEA708 Closed Captions

  • Six configurable Dual Color Status LED´s

  • USB and Micro SD Inhterface for .MP4 or .TS Format Video Archiving

  • Web-Based /Wireless Configuration and Video Monitoring

  • HDMI Output for true Post-Processing Monitoring of any Input

  • Included Mounting Features – Desktop, Wall Brackets, 1/4“ Camera Mount

  • Optional: 1U Sibe by Side Rackmount Option with included Redundant Power Supplies

Video Inputs

  • 1 x HDMI 1.4 4K30 UHD (Full Size Type A)

  • 2 x 3G-SDI 1080P60 (Full Size BNC)

Audio Inputs

  • 2 x Embedded SDI (4 Stereo Pairs for each SDI Input)

  • 1 x Embedded HDMI (4 Stereo Pairs)

  • 1 x Analog Unbalanced Stereo

Video Input Resolutions

  • Up to 3840x2160 30fps on HDMI

  • Up to 1920x1080 60fps on SDI

Streaming Transports

  • RTMP, UDP, RTP, RTSP, SRT™, Zixi™

  • Saving MP4 and TS file

  • CDN Integrations

Video Processing

  • Upscale and Downscale, Frame Rate Conversion, De-Interlacing

  • Text Overlay, Region of Interest, Image Rotation

Video Compression

  • H.264 (AVC), H.265 (HEVC), MJPEG

Encoding Controls

  • Maximum 100Mbit/s Total Output Bitrate

  • Frame Rate Full, Half, Quarter, Sixth

Closed Captions

  • Re-Embeds existing CEA608/708 captions

Audio Compression

  • AAC-LC, AAC-HE, AAC-HEv2

Audio Sample Rate

  • 32KHz, 44.1KHz, 48KHz

  • Audio Bitrate 12Kbps to 384Kbps

  • Power 9VDC to 15,4 VDC/ 7W

  • Operating Temperature: 0°C - 40°C

  • Weight: -

  • Dimensions: 18,8 x 8,8 x 3,8cm

  • Warranty: 2 years

  • 1x Talon Pro Hardware Encoder

  • 1x Country Specific locking Power Supply

  • 1x Pair of Wall Mount Brackets
